Cooler master MASTERBOX Q500L casing MODEL NUMBER MCB-Q500L-KANN-S00 EXTERIOR COLOR Black MATERIALS – BODY Steel, Plastic MATERIALS – SIDE PANEL Acrylic DIMENSIONS (LXWXH) 386(L) x 230(W) x 381(H) mm MOTHERBOARD SUPPORT ATX, Micro ATX, Mini ITX EXPANSION SLOTS 7 5.25″ DRIVE BAYS 0 2.5″ / 3.5″ DRIVE BAYS (COMBO) 2 (each bay supports: 1 HDD or 2 SSDs) 2.5″ DRIVE BAYS 0 I/O PANEL 2x USB 3.0, 1x 3.5mm Audio Jack, 1x 3.5mm Mic Jack PRE-INSTALLED FANS – REAR 1x 120mm FAN SUPPORT – TOP 2x 120/140mm FAN SUPPORT – REAR 1x 120mm FAN SUPPORT – BOTTOM 2x 120mm RADIATOR SUPPORT – TOP 120 / 240mm (35mm max motherboard component height) RADIATOR SUPPORT – REAR 120mm CLEARANCE – CPU COOLER 160mm/6.29″ CLEARANCE – PSU 180mm/7.08″ CLEARANCE – GFX 360mm/14.17″ (270mm clearance with PSUs longer than 160mm) CABLE ROUTING 27-30mm DUST FILTERS Bottom POWER SUPPLY SUPPORT Top Front Mount, ATX PS2 EAN CODE 4719512080580 UPC CODE 884102053078 SERIES MasterBox Series SIZE Mid Tower
