Basic Information Supported CPU Intel Socket 1150 for 4th Generation Core i7/Core i5/Core i3/Pentium/Celeron Processors Supports Intel 22 nm CPU Supports Intel Turbo Boost Technology 2.0 Chipset Intel H81 BIOS 64 Mb Flash ROM, UEFI AMI BIOS, PnP, DMI2.0, WfM2.0, SM BIOS 2.7, ACPI 2.0a, Multi-language BIOS, ASUS EZ Flash 2, ASUS CrashFree BIOS 3, My Favorites, Quick Note, Last Modified log, F12 PrintScreen, F3 Shortcut functions and ASUS DRAM SPD (Serial Presence Detect) memory information Form Factor uATX Form Factor 8.9 inch x 6.9 inch ( 22.6 cm x 17.5 cm ) Audio Realtek ALC887/897 8-Channel High Definition Audio CODEC – Supports : Front Panel Jack-retasking, up to 24-Bit/192kHz playback Expansion Slots PCI 1 x PCIe x16 2 x PCIe 2.0 x1 Memory Type DDR3 Slots 2 x DIMM Supported Memory 1600/1333/1066 MHz Non-ECC, Un-buffered Memory Dual Channel Memory Architecture Supports Intel® Extreme Memory Profile (XMP) Maximum Memory Max. 16GB Graphics Graphics Integrated Graphics Processor Multi-VGA output support : DVI/RGB ports – Supports DVI with max. resolution 1920 x 1200 @ 60 Hz – Supports RGB with max. resolution 1920 x 1200 @ 60 Hz Supports Intel InTru 3D, Quick Sync Video, Clear Video HD Technology, Insider Max Shared Memory 1024 MB Connector & Ports D-Sub (s) 1 x D-Sub DVI-D (s) 1 x DVI USB (s) Intel H81 chipset : 2 x USB 3.1 Gen 1 port(s) (2 at back panel, blue) Intel H81 chipset : 6 x USB 2.0 port(s) (2 at back panel, black, 4 at mid-board) LAN Port (s) Realtek 8111G, 1 x Gigabit LAN Controller(s) Supported Storage Intel H81 chipset : 2 x SATA 6Gb/s port(s), yellow, 2 x SATA 3Gb/s port(s), dark brown, Supports Intel Rapid Start Technology, Intel Smart Connect Technology Audio 3 x Audio jack(s) Internal I/O Ports 1 x CPU Fan connector(s) (1 x 4 -pin) 1 x Chassis Fan connector(s) (1 x 4 -pin) 2 x USB 2.0 connector(s) support(s) additional 4 USB 2.0 port(s) 2 x SATA 6Gb/s connector(s) 2 x SATA 3Gb/s connector(s) 1 x S/PDIF out header(s) 1 x 24-pin EATX Power connector(s) 1 x 4-pin ATX 12V Power connector(s) 1 x Front panel connector(s) 1 x Front panel audio connector(s) (AAFP) 1 x Internal speaker connector(s) 1 x Clear CMOS jumper(s) Warranty Information Manufacturing Warranty 3 Years Others Special Features ASUS EPU : – EPU ASUS Exclusive Features : – GPU Boost – AI Suite 3 – Ai Charger – Anti-Surge – ASUS UEFI BIOS EZ Mode featuring friendly graphics user interface – Network iControl – USB 3.0 Boost – Disk Unlocker ASUS Quiet Thermal Solution : – Stylish Fanless Design Heat-sink solution – ASUS Fan Xpert ASUS EZ DIY : – ASUS CrashFree BIOS 3 – ASUS EZ Flash 2 ASUS Q-Design : – ASUS Q-Slot
